Specification
|
|
|
J1939 male plug
|
standard,12V/24V
|
|
Pins of J1939 male plug
|
Copper,nickel-plated or gold-plated
|
|
Overmold ofJ1939male plug
|
straight
|
|
J1939 female connector
|
standard
|
|
Cable shape
|
Round
|
|
Wire
|
26AWG, pure copper
|
|
Material of overmolded part
|
PVC
|
|
Pin assignment or pin out
|
customized
|
|
Cable length
|
customized
|
|
Pins or terminals
|
copper, nickel-plated or gold-plated
|
|
Contact Resistance
|
3 ohm max.
|
|
Insulation Resistance
|
5M ohm min.
|
|
Working Temperature
|
−25℃ ~ +85℃
|
|
Testing
|
100% open, short and mis-wire testing
|
|
Testing Voltage
|
DC300V 5M ohm/10ms
|
|
Warranty
|
1 year
|
